Box-Type Analog Tilt Meter

Box-Type Analog Tilt Meter

Model EAN-91M

View Related Products
ManualData Sheet - English

Description

The EAN-91M tilt meter can be directly fixed on a wall/structure. The option is also available to fix the EAN-91M tilt meter to a beam of length 1 m, 2 m, and 3 m and use it as a beam sensor for monitoring of differential movement and rotation in structures. It is also used for monitoring deflection and deformation of retaining walls.

Compare Our Products

Model EAN-95MW
Model EAN-95MW

Instrument Name

Wireless tilt meter

—

—

Sensor Type

Digital MEMS (SDI-12), biaxial

—

—

Construction

Box type, with RF communication, in-built datalogger

—

—

Application

Remote tilt monitoring of structures like buildings, dams, tunnel, retaining walls, etc

—

—

Parameter

Tilt/rotation

—

—

Range

± 15°

—

—

Key Testing / Calibration

Accuracy test, individually calibrated, providing high accuracy & repeatability

—

—

Key Feature/Advantage

Can be used at location without cellular network, long batery life for standalone operation, in-built datalogger

—

—

Protection (Waterproofing)

Corrosion resistant weather proof enclosure

—

—

Dimension (mm)

120 x 122 x 90 (LxWXH)

—

—
